Wintergarden By Silent Gliss

Architects’ and clients’ preference for the large glazed areas is made possible by modern technology continuing unabated.

With large glazed areas come large problems of heat (solar gain), light, privacy and glare as well as all of the advantages. Silent Gliss Skylight systems help attenuate these.

Crank operated Wintergarden system for residential as well as contract applications.

Features:
·         Horizontal, sloping (max. 45°), bent (min. radius 20 cm) and arched applications possible.
·         Blinds can be linked and operated from a single crank.
·         Pleasing roman effect with Silent Gliss technical or decorative fabrics. Large and attractive fabric offer.
·         Side guide rails can be custom bent to a min. radius of 20 cm.
·         The maximum dimensions depend on fabric weight, number of connected systems and applications. Please refer to the specific load chart.
·         The maximum dimensions of a horizontal application are 6 m height and 2.4 m width (one system), resp. 3 m width (double system).
·         The max. weight of the fabric including the cross bars should never exceed 10 kg. Large and attractive fabric offer.
·         Left or right hand operation possible. The crank may be detached for security.
·         Multitude of fitting alternatives on all kind of surfaces.
·         Standard profile colours: anodised aluminium or white powder coated.
·         Custom colours on application.

Electrically operated Wintergarden system for residential as well as contract applications.
Features:
·          Electrically operated wintergarden system for residential as well as contract applications.
·          Horizontal, sloping (max. 45°), bent (min. radius 20 cm), and arched applications possible.
·          Blinds can be single, double or triple operated with one motor.
·          Pleasing roman effect with Silent Gliss technical or decorative fabrics. Large and attractive fabric offer.
·          The maximum dimensions depend on fabric weight, number of connected systems and applications. Please refer to the specific load chart.
·          The maximum dimensions of a horizontal application are 6 m height and 2.4 m width (one system), resp. 6 m width (triple system).
·          The max. weight of the fabric including the cross bars should never exceed 10 kg. Large and attractive fabric offer.
·          Multitude of fitting alternatives on all kind of surfaces.
·          Standard profile colours: anodised aluminium or white powder coated.
·          Custom paint colours on application.
·          All hardware, including motor is concealed in headbox and hidden behind the fabric.
·          The system 2195 is equipped with the Silent Gliss motor 2160, a precision-engineered Swiss motor: 230V/50Hz.
·          Can be operated by fixed switch or remote control.
